SNAPNRACK, ULTRA RAIL TILT-MOUNT KIT, 10"

KEY FEATURES:
- Ultra Rail Tilt‑Mount Kit, 10", for UR‑40/UR‑45 Ultra Rail, used on flat and low‑slope roofs as a tilt component and roof attachment with the OmniBase.
- Kit contents (per datasheet): OmniBase casting, 10" standoff shaft, standoff clamp, Ultra Rail mount pieces (tapped and thru), AP90 stepped L‑foot, rail clamp spring, and stainless hardware.
- Materials: 6000‑series aluminum, A380 cast aluminum, and 300‑series stainless steel; UL 2703 listed with design loads of 655 lb up, 1333 lb down, 190 lb side, 161 lb lateral for the tilt‑mount assembly
